Product Model
XB4RFB01
Key Features
- 1High-performance power supply with 1000W output capacity.
- 2Compact design for easy integration into various systems.
- 3Wide input voltage range (85-264VAC) for flexibility.
- 4Low noise operation and high efficiency (up to 92%).
- 5Built-in protection features for enhanced reliability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony XB4R | Product or Component Type | Wireless and batteryless package |
| Device short name | XB4R | Head material | Metal |
| frequency | 2405 MHz transmitter<br />2405 MHz receiver | emission class | 5M00G7W |
| Antenna type | Omnidirectional | Control type | Wireless and batteryless push-button Ø 22 mm assembled on fixing collar |
| Type of receiver | Non-programmable receiver 1 relay) | [Us] Rated Supply Voltage | 24 V DC |
| Kit composition | 1 fixing collars<br />1 0.9 in (22 mm)<br />1 push-button head 0.9 in (22 mm)<br />1 transmitter<br />1 receiver<br />1 set of caps | Communication port protocol | Zigbee IEEE 802.15.4 |
| Max power consumption in W | 1 mW | Number of Channels | 1 |
| Modulation technique | O-QPSK | Bandwidth | 5 MHz |
| Antenna gain | 0 dBi | Customizable | No |
| Compatibility code | XB4R | [Us] rated supply voltage | 24 V |
| Product Certifications | CCC<br />C-tick<br />GOST<br />CSA<br />UL | marking | CE |
| Standards | UL 508<br />EN/IEC 60947-1<br />CSA C22.2 No 14<br />EN/IEC 60947-5-1 | Radio agreement | ARIB T66<br />RSS<br />ICASA<br />SRRC<br />FCC<br />ANATEL |
Specifications may be subject to change without notice
