Product Model
XB4BW11B5
Key Features
- 1High-performance power supply with 11 kW output.
- 2Compact design for easy installation in various settings.
- 3Robust construction for reliable operation under heavy loads.
- 4Advanced thermal management for optimal performance and longevity.
- 5Compliant with international safety standards for peace of mind.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Bezel material | Chromium plated metal | Device short name | XB4 |
| Enclosure type | Corrosion resistance enclosure indoor/outdoor | Light source | White LED |
| Mounting diameter | 0.9 in (22 mm) | Operator additional information | Extended metallic guard |
| Line Rated Current | 10 A | Cap/operator or lens colour | white |
| Contacts type and composition | 1 NO + 1 NC | Control type | illuminated push-button |
| Electrical connection | Screw clamp terminal | Light block supply | Direct 24 V |
| Marking | unmarked | Mounting support | panel |
| Permissible voltage | 600 V | Shape | Round head |
| Type of operator | Momentary | Utilisation category | AC-15<br />DC-13 |
| NEMA Degree of Protection | NEMA 4/4X/13 | Product Certifications | CSA LR44087 class 3211 03<br />CE<br />UL listed file E164353 CCN NKCR |
Specifications may be subject to change without notice
