Product Model
TM171VEVA2
Key Features
- 1High-performance motor with enhanced efficiency.
- 2Robust design for long-lasting durability.
- 3Advanced thermal management for optimal performance.
- 4Easy integration with existing systems.
- 5Energy-saving capabilities for reduced costs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M171 | Product or Component Type | Controller |
| Input/output number | 2 total)<br />1 analog input<br />1 digital output | Sensor power supply | 5 V DC |
| Discrete output number | 1 open collector | Analogue input number | 1 analog input NTC 4...20 mA or 0...5 V or 0...10 V |
| [Us] rated supply voltage | 24 V +/- 10 % AC/DC | Display Type | Without Display |
| Mounting Support | DIN rail | Width | 2.8 in (70.2 mm) |
| Height | 3.4 in (87 mm) | Depth | 2.4 in (61.6 mm) |
| marking | CE | Ambient air temperature for operation | 23…122 °F (-5…50 °C) |
| IP degree of protection | IP20 |
Specifications may be subject to change without notice
