Product Model
TM171DWAL2U
Key Features
- 1High-capacity power distribution with 16 A per phase.
- 2Compact design for easy installation in various environments.
- 3Enhanced safety features including arc fault protection.
- 4Modular design for easy maintenance and upgrades.
- 5Compliant with international safety standards for peace of mind.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M171 | Product or Component Type | Display module |
| Display colour | Monochrome | Supply | External source |
| Display Type | LCD screen | Number of key | 4 |
| Color | White | [Us] rated supply voltage | 12 V DC |
| Power consumption in W | 5 W<br />0 W | marking | CE |
| Realtime clock | With | Local signalling | LCD display |
| Product Compatibility | Logic controller M171 optimized | Height | 5.4 in (137 mm) |
| Width | 3.8 in (96.5 mm) | Depth | 1.2 in (31.3 mm) |
| Net Weight | 0.315 lb(US) (0.143 kg) | Product Certifications | cURus |
| IP degree of protection | IP40 front face: |
Specifications may be subject to change without notice
