Product Model
TM171DWAL2L
Key Features
- 1High reliability and durability for long-lasting performance.
- 2Efficient power distribution with minimal energy loss.
- 3Advanced monitoring capabilities for real-time system insights.
- 4Compact design for easy integration into various applications.
- 5Compliance with international safety standards for secure operation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M171 | Product or Component Type | Display module |
| Display colour | Monochrome | Supply | External source |
| Display Type | Backlit LCD screen | Number of key | 4 |
| Color | White | [Us] rated supply voltage | 12 V DC |
| Power consumption in W | 0 W<br />5 W | Marking | CE |
| Realtime clock | With | Local signalling | LCD display |
| Product Compatibility | Logic controller M171 optimized | Height | 5.4 in (137 mm) |
| Width | 3.8 in (96.5 mm) | Depth | 1.2 in (31.3 mm) |
| Net Weight | 0.315 lb(US) (0.143 kg) | Product Certifications | cURus |
| IP degree of protection | IP40 front face: |
Specifications may be subject to change without notice
