Product Model
TM171DLED
Key Features
- 1High efficiency with up to 95% power factor
- 2Compact design for easy integration in various applications
- 3Robust construction for long-lasting performance
- 4Wide input voltage range for flexibility in installations
- 5Compliant with international safety standards for peace of mind
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M171 | Product or Component Type | Display module |
| Display colour | Monochrome | Supply | External source |
| Display Type | 7 segments LED + decimal point | Number of key | 8 |
| Color | Gray | [Us] rated supply voltage | 12 V DC |
| Power consumption in W | 5 W<br />0 W | Marking | CE |
| Local signalling | LED | Product Compatibility | Logic controller M171 optimized |
| Height | 2.9 in (74 mm) | Width | 1.3 in (32 mm) |
| Depth | 1.2 in (30 mm) | Net Weight | 0.093 lb(US) (0.042 kg) |
| Product Certifications | cURus | IP degree of protection | IP20 |
Specifications may be subject to change without notice
