Product Model
TM171ALON
Key Features
- 1High-capacity power distribution for demanding applications.
- 2Compact design with enhanced thermal management.
- 3Advanced circuit protection for safety and reliability.
- 4Easy installation and maintenance with intuitive controls.
- 5Compliant with international safety standards for peace of mind.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M171/M172 | Product or Component Type | Communication module |
| communication port protocol | LonWorks | Integrated connection type | LON wire crimp - twisted pair |
| Transmission rate | 78 kbits/s | Adjustment | Pitch 3.81 mm |
| Electrical connection | removable screw terminal block | Physical interface | 90° insertion - 0.004 in² (2.5 mm²) cable |
| Supply | Via base board M171P/M172P | Local signalling | for service 1 LED (red)<br /> for status 1 LED (green) |
| Product Compatibility | Logic controller M171 performance<br />Logic controller M172 performance | Net Weight | 0.170 lb(US) (0.077 kg) |
| Product Certifications | EAC<br />CSA<br />CE<br />cURus | marking | CE |
| IP Degree of Protection | IP20 | Ambient Air Temperature for Operation | 14…131 °F (-10…55 °C) |
| Ambient Air Temperature for Storage | -4…185 °F (-20…85 °C) | Relative Humidity | 10…90 % without condensation |
Specifications may be subject to change without notice
