Product Model
140CRP93100C
Key Features
- 1High-performance relay module with 10A contact capacity.
- 2Compact design for easy integration into control panels.
- 3Reliable operation in harsh industrial environments.
- 4Compatible with a wide range of control systems.
- 5Durable construction with long lifespan.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon Quantum automation platform | Product or Component Type | RIO head-end adaptor module |
| Product Compatibility | Quantum 200/500/800 series<br />Symax (any mix) | Maximum drops/network | 31 |
| I/O words/drop | 64 I/64 O | Type of cable | 75 Ohm coaxial |
| Transmission Rate | 1544 Mbit/s | Dynamic range | 35 dB |
| Isolation voltage | 500 V DC coaxial center and ground | Electrical connection | 1 female connector F, elbowed with single cable |
| Diagnostics startup | LAN controller check<br />Memory check<br />Power up | Power dissipation in W | 3 W 1 channel |
| marking | CE | Bus current requirement | 600 mA 1 channel |
| Module format | Standard | Protective treatment | Conformal coating Humiseal 1A33 |
| Product Certifications | FM Class 1 Division 2 | Standards | CSA C22.2 No 142<br />CUL<br />UL 508 |
| Resistance to electrostatic discharge | 4 kV contact IEC 801-2<br />8 kV on air IEC 801-2 | Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80…1000 MHz IEC 801-3 |
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) | Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Relative Humidity | 95 % without condensation | Operating altitude | <= 16404.2 ft (5000 m) |
Specifications may be subject to change without notice
