Product Model
UK 10,3-HESI A
Key Features
- 11500V rating for demanding industrial environments.
- 2Reliable and durable glass fuse ensures consistent performance.
- 3Easy to install and connect with modular terminal block design.
- 423 mm width with 2 connections, perfect for space-constrained setups.
- 5Available at a discounted price of $25.19 per unit.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product type | Fuse terminal block | Number of connections | 2 |
| Number of rows | 1 | Article revision | 00 |
| Overvoltage category | III | Degree of pollution | 3 |
| Fuse type | Glass / ceramics / ... | Rated surge voltage | 6 kV |
| Fuse | 10.3 x 38 mm | Number of connections per level | 2 |
| Nominal cross section | 16 mm² | Rated cross section AWG | 6 |
| Screw thread | M4 | Tightening torque | 1.5 ... 1.8 Nm |
| Stripping length | 12 mm ... 14 mm | Internal cylindrical gage | A7 |
| Connection in acc. with standard | IEC 60947-1 / -3 | Conductor cross section rigid | 0.75 mm² ... 25 mm² |
| Cross section AWG | 16 ... 3 (converted acc. to IEC) | Conductor cross section flexible | 0.75 mm² ... 25 mm² |
| Conductor cross section, flexible [AWG] | 18 ... 3 (converted acc. to IEC) | Conductor cross-section flexible (ferrule without plastic sleeve) | 0.75 mm² ... 16 mm² |
| Flexible conductor cross section (ferrule with plastic sleeve) | 0.75 mm² ... 16 mm² | Cross-section with insertion bridge, rigid | 10 mm² |
| Cross-section with insertion bridge, flexible | 10 mm² | 2 conductors with same cross section, solid | 0.75 mm² ... 10 mm² |
| 2 conductors with same cross section, flexible | 0.75 mm² ... 10 mm² | 2 conductors with same cross section, flexible, with ferrule without plastic sleeve | 0.75 mm² ... 6 mm² |
| Nominal current | 32 A (the current and voltage are determined by the fuse) | Maximum load current | 32 A (the current and voltage are determined by the fuse) |
| Nominal voltage | 690 V (the current and voltage are determined by the fuse) | Nominal cross section | 16 mm² |
| Width | 17.8 mm | Height | 66.8 mm |
| Color | black | Flammability rating according to UL 94 | V0 |
| Insulating material group | I | Insulating material | PA |
| Open side panel | No | Connection in acc. with standard | IEC 60947-1 / -3 |
| Mounting type | NS 35/7,5
NS 35/15 |
Specifications may be subject to change without notice
