Product Model
RAD-ISM-900-DATA-BD-BUS-NZ
Key Features
- 1Operates in the 900 MHz ISM band for reliable wireless communication.
- 2Supports RS-232, RS-485/RS-422 interfaces for easy integration with various systems.
- 3Enables connection to additional I/O modules for expanded functionality.
- 4Ensures robust performance in noisy industrial environments.
- 5Suitable for mounting in small enclosures due to surface mount components.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product type | Wireless module | Supply voltage | 24 V DC |
| Supply voltage range | 9 V DC ... 30 V DC | Typical current consumption | 110 mA |
| Max. current consumption | 180 mA | Connection method | Screw connection |
| Stripping length | 8 mm | Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
| Conductor cross section rigid | 0.2 mm² ... 4 mm² | Cross section AWG | 24 ... 12 |
| Screw thread | M3 | Data rate | 1,2 / 2,4 / 9,6 / 19,2 / 38,4 kBit/s |
| Connection method | D-SUB-9 female connector | File format/coding | Asynchronous |
| Data flow control/protocols | RTS/CTS | Data rate | 1,2 / 2,4 / 9,6 / 19,2 / 38,4 kBit/s |
| Connection method | COMBICON plug-in screw terminal block | Direction | Bi-directional |
| Frequency | 900 MHz | Frequency range | 921.4 MHz ... 927.7 MHz |
| Number of channel groups | 1 | Number of channels per group | 63 |
| Transmission power | 1 W | Frequency band | 900 MHz |
| Width | 22.5 mm | Height | 99 mm |
| Depth | 114.5 mm | Color | green |
| Housing material | Polyamide PA non-reinforced | Degree of protection | IP20 |
| Ambient temperature (operation) | -40 °C ... 70 °C
-40 °F ... 158 °F | Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Electromagnetic compatibility | FCC Part 15.247 | Assembly note | on standard DIN rail NS 35 in accordance with EN 60715 |
| Mounting position | any |
Specifications may be subject to change without notice
