Product Model
PLC-OSP-120UC/230AC/ 1
Key Features
- 1High Reliability: Built with durable components for consistent performance.
- 2Fast Response Time: Typical response time of 10 ms at UN voltage.
- 3Compact Design: Compact size for easy integration into industrial systems.
- 4Wide Operating Range: Compatible with 120 VDC and 230 VAC inputs.
- 5Enhanced Safety: Solid-state technology ensures safe and reliable operation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| EMC note | EMC: class A product, see manufacturer's declaration in the download area | Product type | Solid-state relay module |
| Product family | PLC-INTERFACE | Application | Universal |
| Operating mode | 100% operating factor | Date of last data management | 25.04.2023 |
| Insulation | Basic insulation | Overvoltage category | III |
| Pollution degree | 2 | Test voltage (Input/output) | 2.5 kV (50 Hz, 1 min., input/output) |
| Nominal input voltage U | 120 V AC
110 V DC | Input voltage range in reference to U | 0.9 ... 1.1 |
| Input voltage range | 108 V AC ... 132 V AC
99 V DC ... 121 V DC | Switching threshold "0" signal in reference to U | ≤ 0.25 |
| Switching threshold "1" signal in reference to U | ≥ 0.8 | Typical input current at U | 4 mA |
| Typical response time | 10 ms (at U | Typical turn-off time | 10 ms (at U |
| Operating voltage display | Yellow LED | Protective circuit | Bridge rectifier; Bridge rectifier |
| Transmission frequency | 3 Hz | Contact switching type | 1 N/O contact |
| Design of digital output | electronic | Output voltage range | 24 V AC ... 253 V AC |
| Limiting continuous current | 0.75 A (see derating curve) | Maximum inrush current | 30 A (10 ms) |
| Min. load current | 10 mA | Leakage current | < 1 mA (in off state) |
| Phase angle cos phi min | 0.5 | Max. load value | 4.5 A |
| Voltage drop at max. limiting continuous current | < 1 V | Output circuit | 2-conductor, floating |
| Protective circuit | RCV circuit | Connection method | Spring-cage connection |
| Stripping length | 8 mm | Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
| Conductor cross section flexible | 0.14 mm² ... 2.5 mm² | Conductor cross section AWG | 26 ... 14 |
| Connection method | Spring-cage connection | Stripping length | 8 mm |
| Conductor cross section rigid | 0.14 mm² ... 2.5 mm² | Conductor cross section flexible | 0.14 mm² ... 2.5 mm² |
| Conductor cross section AWG | 26 ... 14 | Width | 6.2 mm |
| Height | 80 mm | Depth | 94 mm |
| Color | green (RAL 6021) | Flammability rating according to UL 94 | V0 (Housing) |
| Ambient temperature (operation) | -25 °C ... 60 °C | Ambient temperature (storage/transport) | -25 °C ... 70 °C |
| Standards/regulations | IEC 60664
EN 50178 | Assembly note | in rows with zero spacing |
| Mounting position | any |
Specifications may be subject to change without notice
