Product Model
ILC 155 ETH
Key Features
- 1High-Performance Mining: The ILC 155 ETH is engineered to deliver superior mining performance, ensuring you maximize your cryptocurrency earnings.
- 2Energy Efficiency: Designed with energy efficiency in mind, this rig minimizes power consumption while maintaining high hash rates, reducing operational costs.
- 3Advanced Cooling System: Equipped with an advanced cooling system, the ILC 155 ETH keeps your mining equipment at optimal temperatures, extending its lifespan.
- 4User-Friendly Interface: Featuring a user-friendly interface, this rig is easy to set up and monitor, making it perfect for both beginners and experienced miners.
- 5Enhanced Security: Built with robust security features, the ILC 155 ETH protects your investments from potential threats, ensuring a secure mining experience.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| EMC note | EMC: class A product, see manufacturer's declaration in the download area | Product type | Controller |
| Product family | Inline | Type | Inline format with alignable I/Os |
| Diagnostics display | no | Retentive data storage | 48 kByte (NVRAM) |
| Program memory | 512 kByte | Data storage system | 512 kByte |
| Number of control tasks | 8 | Amount of process data | max. 4096 bit (INTERBUS) |
| Number of supported devices | max. 128 | Number of local bus devices that can be connected | max. 63 (observe current consumption) |
| Number of devices with parameter channel | max. 16 | Number of supported branch terminals with remote bus branch | max. 3 |
| Diagnostics display | no | Controller redundancy | no |
| Engineering tool | PC Worx
PC Worx Express | Configuration tool | Config+ Version 1.01 or later |
| Diagnostics tool | DIAG+ | Runtime system | eCLR |
| Application interface | OPC | Transmission medium | Copper |
| Maximum power dissipation for nominal condition | max. 5 W | Supply voltage | 24 V DC |
| Supply voltage range | 19.2 V DC ... 30 V DC | Residual ripple | ± 5 % |
| Max. current consumption | 870 mA (370 mA communications power + 500 mA analog voltage supply) | Typical current consumption | 210 mA |
| Realtime clock | yes | Description realtime clock | integrated (rechargeable battery buffered) |
| Supply voltage | 7.5 V DC ±5 % | Supply voltage | 24 V DC -15 % / +20 % |
| Supply voltage | 24 V DC -15 % / +20 % (in accordance with EN 61131-2) | Current draw | 8 A DC |
| Supply voltage | 24 V DC -15 % / +20 % (in accordance with EN 61131-2) | Current draw | 8 A DC |
| Input name | Digital inputs | Number of inputs | 8 |
| Connection method | Inline potential distributor | Connection technology | 2-, 3-, 4-conductor |
| Output name | Digital outputs | Connection method | Spring-cage connection |
| Connection technology | 2-, 3-, 4-conductor | Number of outputs | 4 |
| Maximum output current per channel | 500 mA | Connection method | Spring-cage connection |
| Conductor cross section, rigid | 0.08 mm² ... 1.5 mm² | Conductor cross section, flexible | 0.08 mm² ... 1.5 mm² |
| Conductor cross section AWG | 28 ... 16 | Connection method | Inline data jumper |
| Transmission speed | 500 kBaud / 2 MBaud (can be switched) | Bus system | RS-232 |
| Connection method | RS-232-C, 6-pos. MINI-DIN socket (PS/2), Ethernet 10/100 (RJ45) | Transmission speed | max. 115.2 kbps |
| Transmission physics | Copper | No. of channels | 1 |
| Bus system | RJ45 | Connection method | RJ45 jack |
| Transmission speed | 10/100 Mbps | No. of channels | 1 |
| Width | 80 mm | Height | 119.8 mm |
| Depth | 71.5 mm | Color | green (RAL 6021) |
| Degree of protection | IP20 | Ambient temperature (operation) | -25 °C ... 55 °C |
| Ambient temperature (storage/transport) | -25 °C ... 85 °C | Permissible humidity (operation) | 10 % ... 95 % (according to DIN EN 61131-2) |
| Permissible humidity (storage/transport) | 10 % ... 95 % (according to DIN EN 61131-2) | Shock | 25g, Criterion 1, according to IEC 60068-2-27 |
| Vibration (operation) | 5g | Air pressure (operation) | 70 kPa ... 106 kPa (up to 3000 m above sea level) |
| Air pressure (storage/transport) | 70 kPa ... 106 kPa (up to 3000 m above sea level) | Mounting type | DIN rail mounting |
Specifications may be subject to change without notice
