Product Model
FLKM 16/LA
Key Features
- No key features available for this product.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product type | Interface module | Product family | VARIOFACE |
| Number of positions | 16 | Overvoltage category | II |
| Pollution degree | 2 | Nominal voltage U | 24 V DC |
| Max. current carrying capacity per branch | 1 A | Connection in acc. with standard | IEC / EN |
| Connection method | Screw connection | Stripping length | 8 mm |
| Screw thread | M3 | Conductor cross section rigid | 0.2 mm² ... 4 mm² |
| Conductor cross section flexible | 0.2 mm² ... 2.5 mm² | Conductor cross section AWG | 24 ... 12 |
| Connection method | IDC/FLK pin strip | Number of positions | 16 |
| Pitch | 2.54 mm | Status display | LED |
| Status display present | Yes | Width | 56.5 mm |
| Height | 58.5 mm | Depth | 77 mm |
| Color | green (RAL 6021) | Housing insulation material | Polyamide 6.6 green |
| Ambient temperature (operation) | -20 °C ... 50 °C | Ambient temperature (storage/transport) | -20 °C ... 70 °C |
| Standards/regulations | IEC 60664
DIN EN 50178 | Mounting position | any |
| Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
