Product Model
WFK2-005AAAAN
Key Features
- 1High Accuracy: ±2.5%F.S. analog accuracy and ±2.5%F.S. display accuracy.
- 2Wide Flow Rate Range: Handles flow rates from 0.4 to 5 L/min.
- 3Easy Flow Rate Adjustments: Manual valve integration for easy adjustments.
- 4Integrated Temperature Measurement: Standard fluid temperature measurement up to 95°C.
- 5IO-Link Compatibility: Supports remote control and data collection via IO-Link communication.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | WFK2 | Range of flow rate | 005 : 0.4~5L/min |
| Port size | AA : Rc 3/8 | IO-Link / analog output | A : Switch (Analog output) DC0~5V/DC1~5V |
| Display Unit | A : L/min m^3 °C | Manual valve | N : Sensor only |
| Height of knob | 0.0mm | Option (Cable) | Blank : None |
| Option (Bracket) | Blank : None | Option (other) | Blank : None |
Specifications may be subject to change without notice
