Product Model
VCV-H20
Key Features
- 1Weatherproof/dust-tight housing with IP68 rating.
- 2IK10 vandal-proof compliance enclosure for added security.
- 3Die-cast aluminum body for durability and strength.
- 4Suitable for wall mounting with open access for wiring and service.
- 5Easy setup and minimal installation requirements.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model No. | VCV | Performance | H : High vacuum type |
| Nozzle diameter | 20 | Pressure switch | Blank : Without pressure switch |
| A | 85mm | B | 40mm |
| C | 30mm | D | 15mm |
| E | 13mm | F | 28mm |
| G | 32mm | H | 7.0mm |
| 2-ΦI(Mounting hole) | 6.0mm | J | Rp3/8 |
| K | 20mm | L | Rp1/4 |
| M | 56mm | N(Φ) | 28mm |
| O | 24mm | P | 161mm |
Specifications may be subject to change without notice
