Product Model
SCWR-LB-25
Key Features
- 1Compact design with bore sizes φ8 to φ25.
- 2Robust construction for high-pressure applications.
- 3Compatible with ISO6432 standards for universal use.
- 4Adjustable stroke lengths from 0 to 100mm.
- 5Easy mounting options with precise dimensions.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model | SCWR-LB-25 | Bore | 25mm |
| LA | 11mm | LB | 8mm |
| LC | 17mm | LD | 6.6mm |
| LE | 103.1mm | LF | 40mm |
| LG | 45.1mm | LH | 25mm |
| LK | 20mm | LR | 40mm |
| LS | 54mm | LT | 5mm |
Specifications may be subject to change without notice
