Product Model
SCG-B3-32
Key Features
- 1Double-acting operation for versatile applications.
- 2Stainless steel piston rod for high corrosion resistance.
- 3Customizable stroke lengths available in 1mm increments.
- 4Compatible with compressed air, ensuring reliable operation.
- 5Available in bore sizes from 32 to 100mm for diverse needs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | SCG-B3-32 | Applicable bore size | 32, 40mm |
| C | 6.6mm | CD | 10mm |
| CF | 33mm | CQ | 14mm |
| D | 15mm | F | 7mm |
| G | 6mm | K | 62mm |
| KA | 42mm | KB | 21.0mm |
| MR | 10mm | SD | 44mm |
| SE | 22mm | WEIGHT | 0.21kg |
Specifications may be subject to change without notice
