Product Model
PDVE4-20A-3T-AC100V
Key Features
- 1Ensures safety in environments with explosive gases.
- 2Operates on AC100V, suitable for diverse industrial settings.
- 3Withstands pressures up to 2.76 MPa for reliable performance.
- 4Available in urethane rubber for 20A and 25A models.
- 5Made with stainless steel and aluminum casting for long-lasting service.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model No. | PDVE4 | Port size and diaphragm material | 20A : Rc3/4 |
| Diaphragm material | Urethane rubber | Coil code | 3T |
| Rated voltage | AC100V : 100 VAC(50/60 Hz)/110 VAC(60 Hz) | A | 60mm |
| B | 40mm | C | 31.5mm |
| D | 31mm | E | 113mm |
| F | 156mm | G | 150mm |
| H | Rc3/4 | Weight | 1.21kg |
Specifications may be subject to change without notice
