Product Model
GWY1210-0
Key Features
- 1Compact size for space-saving applications.
- 2Flame-resistant white body with UL94 V-0 equivalent.
- 3Easy push-in installation for quick connections.
- 4Compatible with metric tubes (ø10 and ø12).
- 5Suitable for pneumatic piping systems in various industries.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | GWY1210-0 | Applicable tube O.D.∅ A side | 12mm |
| Applicable tube O.D.∅ B side | 10mm | L | 53.0mm |
| B1 | 23.0mm | B2 | 21.5mm |
| C | 20.0mm | D | 41mm |
| E | 4.2mm | F | 21.0mm |
| J | 32.0mm | N1 | 24.0mm |
| N2 | 19.5mm | P | 21.0mm |
| Effective sectional area | 35.5mm^2 |
Specifications may be subject to change without notice
