Product Model
GWMF610-0
Key Features
- 1Compact size for space-saving applications.
- 2Flame-resistant white body for safe use in various environments.
- 3Push-in installation with V-shaped packing seal for smooth and secure connection.
- 4Easy tubing removal with push ring mechanism.
- 5High reliability and durable design with Teflon resin-coated thread parts.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | GWMF610-0 | Applicable tube O.D.∅ A side | 6mm |
| Applicable tube O.D.∅ B side | 10mm | L1 | 78.5mm |
| L2 | 22.0mm | B1 | 17.5mm |
| B2 | 22.0mm | C | 17.5mm |
| F | 18.5mm | N1 | 13.0mm |
| N2 | 46.5mm | P | 13.0mm |
| Effective sectional area | 30.0mm^2 |
Specifications may be subject to change without notice
