Product Model
GWL12-10-T
Key Features
- 1Compact size for space-saving applications.
- 2V-shaped packing seal ensures smooth insertion and accurate sealing.
- 3Flame-resistant white body (equivalent to UL94 standards V-0).
- 4Electroless nickel plating on brass parts for improved corrosion resistance.
- 5Easy push-in installation with no need for sealing tape.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | GWL12-10-T | Applicable tube O.D.∅ | 12mm |
| M | R3/8 | H | 17mm |
| L1 | 35.5mm | L2 | 39.5mm |
| A | 25.0mm | B | 12.0mm |
| C | 20.0mm | D | 4.0mm |
| E | 22.7mm | Effective sectional area | 32.0mm^2 |
Specifications may be subject to change without notice
