Product Model
XT2V 125 TMA 90-450..900 3p F F UL/CSA + Acc
Key Features
- 1UL/CSA Certification: Meets stringent safety standards for reliable operation.
- 2High Current Rating: Handles up to 90A for efficient power distribution.
- 3Compact Design: XT2 frame size ensures space-saving installation.
- 4Thermomagnetic Release: TMA trip unit provides fast and accurate fault detection.
- 5Front Terminal Connection: Easy access and secure bolt-type terminals.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| CN8 | 85362090 | Country of Origin | Italy (IT) |
| Customs Tariff Number | 85362090 | EAN | 8051785074238 |
| Invoice Description | XT2V 125 TMA 90-450..900 3p F F UL/CSA + Acc | Minimum Order Quantity | 1 piece |
| Order Code US and Canada | XT2VU3090BYD00HXXX | Package Level 1 EAN | 8051785074238 |
| Package Level 1 Units | box 1 piece | Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker | Selling Unit of Measure | piece |
| Short Description | XT2V 125 TMA 90-450..900 3p F F UL/CSA + Acc | WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | Manufacturer ID | 1SDX240164R1 |
Specifications may be subject to change without notice
