Product Model
CR-MX110DC4LT
Key Features
- 1Operates with a 110 V DC rated control supply voltage.
- 2Features 4 c/o (SPDT) contacts rated at 250 V / 5 A.
- 3Includes an integrated blue test button for manual actuation.
- 4Offers cadmium-free contact material for reliability.
- 5Suitable for diverse industrial applications with galvanic isolation and signal separation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Net Width | 21.5 mm | Product Net Height | 37 mm |
| Product Net Depth / Length | 28 mm | Product Net Weight | 0.035 kg |
| Function | Pluggable miniature interface relay CR-MX | Sub-Function | Relay with built in LED |
| Rated Control Supply Voltage (Us) | 110 V DC | Rated Operational Voltage | 250 V AC |
| Output | 4 c/o (SPDT) contacts | Output Signal | 250 V / 5 A |
| Terminal Type | Flat-Pin Connections | Rated Operational Current AC-12 (Ie) | (230 V) 5 A |
| Rated Operational Current AC-15 (Ie) | (120 V) 1.9 A (230 V) 0.8 A | Rated Operational Current DC-12 (Ie) | (24 V) 5 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 1.8 A (120 V) 0.5 A | Rated Impulse Withstand Voltage (Uimp) | Between Coil and Contacts 1.5 kV |
| Rated Insulation Voltage (Ui) | 250 V | Degree of Protection | IP40 |
| Mounting Position | 1 | Standards | CSA 22.2 No. 14 IEC/EN 63000 IEC/EN 61010-1 UL 508 |
| Maximum Operating Voltage UL/CSA | 250 V AC | Flammability According to UL94 | V-2 |
| Ambient Air Temperature | Operation -40 ... +70 °C Storage -40 ... +70 °C | Maximum Operating Altitude Permissible | Without Derating 2000 m |
| Object Classification Code | K | ETIM 7 | EC001437 - Switching relay |
| ETIM 8 | EC001437 - Switching relay | ETIM 9 | EC001437 - Switching relay |
| eClass | V11.0 : 27371601 | UNSPSC | 39122331 |
| Manufacturer ID | 1SVR405643R8100 |
Specifications may be subject to change without notice
