Product Model
CR-M012AC3L
Key Features
- 1High-performance pluggable interface relay with 3PDT contacts.
- 2Rated for 250V/10A, ensuring reliable electrical isolation.
- 3Equipped with an LED indicator for easy status monitoring.
- 4Compact design (21x36x28mm) for space-saving installations.
- 5Globally approved and suitable for diverse industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Net Width | 21 mm | Product Net Height | 36 mm |
| Product Net Depth / Length | 28 mm | Product Net Weight | 0.033 kg |
| Function | Pluggable miniature interface relay CR-M | Sub-Function | Relay with built in LED |
| Rated Control Supply Voltage (Us) | 12 V AC | Rated Operational Voltage | 250 V AC |
| Rated Frequency (f) | 50 / 60 Hz | Output | 3 c/o (SPDT) contacts |
| Output Signal | 250 V / 10 A | Terminal Type | Flat-Pin Connections |
| Rated Operational Current AC-12 (Ie) | (230 V) 10 A | Rated Operational Current AC-15 (Ie) | (120 V) 3 A (230 V) 1.5 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 10 A | Rated Operational Current DC-13 (Ie) | (24 V) 2.5 A (250 V) 0.1 A |
| Rated Insulation Voltage (Ui) | 250 V | Degree of Protection | IP40 |
| Pollution Degree | 3 | Mounting Position | 1 |
| Standards | IEC/EN 63000 IEC/EN 61810-1 UL 508 CAN/CSA C22.2 No.14 | Maximum Operating Voltage UL/CSA | 300 V AC |
| Contact Rating UL/CSA | B300 | Pilot Duty UL/CSA | B300 |
| Flammability According to UL94 | HB | Ambient Air Temperature | Operation -40 ... +55 °C Storage -40 ... +85 °C |
| Maximum Operating Altitude Permissible | Without Derating 2000 m | Object Classification Code | K |
| ETIM 7 | EC001437 - Switching relay | ETIM 8 | EC001437 - Switching relay |
| ETIM 9 | EC001437 - Switching relay | eClass | V11.0 : 27371601 |
| UNSPSC | 39122331 | Manufacturer ID | 1SVR405612R0300 |
Specifications may be subject to change without notice
