Product Model
BCM/S8.0.2.1
Key Features
- 18 Digital Outputs for Versatile Control
- 2Compatible with 230V and 0.3A Output Current
- 3Triac Digital Outputs for Reliable Switching
- 4Compact Design (34 mm x 135 mm x 74 mm)
- 5Configurable Digital Inputs and Outputs
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Degree of Protection | IP20 | Data Sheet, Technical Information | 9AKK107046A7505 |
| Number of Outputs | 8 | Product Range | KNX |
| Manual Operation | No | Number of Batteries | 0 |
| Product Net Width | 34 mm | Product Net Height | 135 mm |
| Product Net Depth / Length | 74 mm | Product Net Weight | 0.18 kg |
| ETIM 9 | EC001419 - PLC digital I/O-module | eClass | V11.0 : 27242204 |
| UNSPSC | 32151705 | Object Classification Code | A |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
| Manufacturer ID | 2CDG120066R0011 |
Specifications may be subject to change without notice
